What is self-unloading iron remover?

Iron remover is a kind of equipment that can generate strong magnetic attraction. It can remove ferromagnetic impurities mixed in materials, so as to ensure the safe and normal operation of crushers, grinders and other mechanical equipment in the conveying system. At the same time, it can effectively prevent the accident of cracking the conveying belt due to large and long iron parts..

How to choose self-unloading iron remover?

1.Select the correct equipment according to the requirements of the impurity removal rate and the environment of the construction site.

2.When installed on the head of the belt conveyor, because the material has inertia, it is in a loose state when it leaves the belt, which is conducive to the removal of ferromagnetic materials in the material.

3.When the equipment is installed in the middle of the belt conveyor, the idler can be changed to a non-magnetic flat idler, so that the effect of iron removal is further improved.

Get Price List

Product features

High-performance NdFeB is used as the magnetic source, the magnetic energy product is high.
Perfect double magnetic pole structure, high magnetic field strength and large suction force.
Fully sealed bearing seat, good sealing performance,and can adapt to various harsh environments.
The control part can be interlocked with the belt conveyor to realize local manual control and centralized control.

Working principle

When the self-unloading iron remover is working, it is suspended above the belt conveyor. When the conveyed material passes through the strong magnetic field of the iron remover, the ferromagnetic substances mixed in the material are firmly adsorbed on the unloading belt . At the same time, the belt is driven by the driving motor to throw the ferromagnetic substances out of the site, thereby achieving the purpose of iron removal.

self-unloading iron remover working principle

Specification

Machine Model	Belt Width (mm)	Rated Height (mm)	Material Thickness (mm)	Magnetic Strengh (Mt)	Motor Power (kw)	Belt Speed (m/s)	Working System	Weight (kg)
RCYD-5	500	150	100	65	1.5	2.5	Continuous	750
RCYD-6.5	650	200	150	70	1.5	2.5	Continuous	1200
RCYD-8	800	250	200	70	2.2	2.5	Continuous	1400
RCYD-10	1000	300	250	70	3.0	2.5	Continuous	2120
RCYD-12	1200	350	300	70	4.0	2.5	Continuous	3350
RCYD-14	1400	400	350	70	4.0	2.5	Continuous	4450
RCYD-16	1600	450	400	70	5.5	2.5	Continuous	6200
