Mining agitator tank - Baichy Machinery

Product Center / Beneficiation Equipment / Agitator

Agitator is the indispensable equipment to fully mix the reagent and the ore pulp, increase the reaction time of the reagent and strengthen the quality of the reagent reaction.

200meshFeed Size
1.1-22KWMotor Power
0.098-30m³Processing capacity

Get Quotes Leave Message

60S Quick Response
30Min Technical Reply
24H Design Proposal
Email:hnbc@baichy.com

What is agitator or mixer?

The mining agitator, also called mixer, is a kind of agitating equipment used for ore pulp agitation before flotation operation, so that ore pulp and reagent are fully mixed. It can also be used for stirring other non-metallic minerals. Mixing barrels are very common in metal and non-metal beneficiation, such as flotation beneficiation, hydrometallurgy, rare and precious metal leaching and extraction, and are also used in many sewage treatment and production of some chemical raw materials.

How to choose mining agitator?

There are five main functions of the mining mixing tank

1.Mixing two or more liquids evenly

2.Disperse two or more incompatible liquids evenly to obtain an emulsion

3.To dissolve certain gases in the liquid,4.

4.Disperse the solid particles evenly in the liquid

5.Accelerate the chemical reaction in the slurry.

According to the function and characteristics of the mixing tank, choose a suitable agitator machine reasonably to improve the flotation efficiency of minerals.

Get Price List

Product features

Excellent Mixing Efficiency

A high-speed impeller creates strong circulation. It ensures chemicals and slurry are mixed uniformly. This process maximizes mineral recovery rates in flotation cells.
High Wear Resistance

The impeller and tank are rubber-lined for durability. This design prevents erosion from abrasive slurries. It ensures a long service life and high reliability in mines.
Improved Mineral Processing Efficiency

Continuous agitation keeps solid particles suspended and enhances contact between minerals and processing agents.
Flexible Application In Beneficiation Plants

Suitable for mixing operations in flotation, chemical treatment, and other mineral separation processes with different slurry conditions.

Working principle

Agitation tank adopts barrel shaped radiation circular spiral impeller for mixing operation by mechanical stirring method. The motor drives V- belt transmission device which drives the impeller. Reagents mix evenly under the rotation of impeller preparing for next step that mix the ore slurry and reagents. Agitation tank for chemical reagent is used for reagents preparation before floatation.

Specification

Model	Internal diameter(mm)	Internal Height(mm)	Volume(m3)	Impeller speed(r/min)	Impeller diameter(mm)	Motor power		Dimension (LxWxH) (mm)
Model	Internal diameter(mm)	Internal Height(mm)	Volume(m3)	Impeller speed(r/min)	Impeller diameter(mm)	Model	Power(KW)	Dimension (LxWxH) (mm)
XB-500	500	500	0.098	600	200	Y90S-6	1.1	600×566×954
XB-750	750	750	0.33	530	255	Y90L-4	1.5	1131×880×1241
XB-1000	1000	1000	0.58	350	240	Y90L-4	1.5	1131×1130×1492
XB-1200	1200	1200	1.18	320	400	Y132S-6	2.2	1500×1480×1800
XB-1500	1500	1500	2.2	320	400	Y132S-6	3	1750×1640×2190
XB-2000	2000	2000	4.4	240	550	Y132M2-6	5.5	2380×2162×2850
XB-2500	2500	2000	9.2	272	650	Y160L-6	11	3036×2716×3543
XB-3000	3000	3000	19.1	220	700	Y225S-8	18.5	3604×3216×4250
XB-3500	3500	3500	30	183	850	Y225M-8	22	3940×3766×5386
